подушечный роликоподшипник
Посадочный роликоподшипник состоит из сферических или конических роликоподшипников, установленных в неразрезной оболочке, которая может быть соединена болтами с опорной поверхностью. Эти устройства запечатаны и смазаны и могут использоваться в любое время. Такие устройства охватывают широкий круг требований. Единицы метрической серии соответствуют пограничным размерам ISO 113. Британские серийные блоки не стандартизированы, но наши роликовые подшипники могут быть взаимозаменяемы по размеру с наиболее распространенными конструкциями на рынке.
Свяжитесь с нами| Designation | Shaft diameter | Unit dimensions | Basic load ratings | Limiting speed | ||||
| Width | Centre height | Bolt distance | Length | dynamic | static | |||
| da [mm]↑↓ | A [mm] | H [mm] | J[mm] | L[mm] | C [kN] | C0[kN] | [r/min] | |
| P2B 103-SRB-SGE | 30.163 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 103-SRB-SGH | 30.163 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 103-SRB-SLE | 30.163 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 103-SRB-SLH | 30.163 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 103-SRB-SRE | 30.163 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2B 103-SRB-SRH | 30.163 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2BE 103-SRB-SGE | 30.163 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 1 700 |
| P2BE 103-SRB-SGH | 30.163 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 1 700 |
| P2BE 103-SRB-SLE | 30.163 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 6 000 |
| P2BE 103-SRB-SLH | 30.163 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 6 000 |
| P2BE 103-SRB-SRE | 30.163 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 5 100 |
| P2BE 103-SRB-SRH | 30.163 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 5 100 |
| P2BE 103-TRB-STH | 30.163 | 46.038 | 38.1 | 121.444 | 152.4 | 54.3 | 64 | 4 300 |
| P2B 104-SRB-SGE | 31.75 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 104-SRB-SGH | 31.75 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 104-SRB-SLE | 31.75 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 104-SRB-SLH | 31.75 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 104-SRB-SRE | 31.75 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2B 104-SRB-SRH | 31.75 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2BE 104-SRB-SGE | 31.75 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 1 700 |
| P2BE 104-SRB-SGH | 31.75 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 1 700 |
| P2BE 104-SRB-SLE | 31.75 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 6 000 |
| P2BE 104-SRB-SLH | 31.75 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 6 000 |
| P2BE 104-SRB-SRE | 31.75 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 5 100 |
| P2BE 104-SRB-SRH | 31.75 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 5 100 |
| P2BE 104-TRB-STH | 31.75 | 46.038 | 38.1 | 121.444 | 152.4 | 54.3 | 64 | 4 300 |
| P2BE 106-TRB-STH | 34.925 | 53.975 | 47.625 | 146.05 | 187.325 | 88.2 | 104 | 3 800 |
| P2BE 35M-TRB-STH | 35 | 53.975 | 47.625 | 146.05 | 187.325 | 82.5 | 104 | 3 800 |
| SYNT 35 F | 35 | 60 | 60 | 170 | 205 | 86.5 | 85 | 4 100 |
| SYNT 35 FTF | 35 | 60 | 60 | 170 | 205 | 86.5 | 85 | 2 050 |
| SYNT 35 FTS | 35 | 60 | 60 | 170 | 205 | 86.5 | 85 | 6 500 |
| SYNT 35 L | 35 | 60 | 60 | 170 | 205 | 86.5 | 85 | 4 100 |
| SYNT 35 LTF | 35 | 60 | 60 | 170 | 205 | 86.5 | 85 | 2 050 |
| SYNT 35 LTS | 35 | 60 | 60 | 170 | 205 | 86.5 | 85 | 6 500 |
| P2B 107-SRB-CLE | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 8 000 |
| P2B 107-SRB-CLH | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 8 000 |
| P2B 107-SRB-CRE | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 4 000 |
| P2B 107-SRB-CRH | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 4 000 |
| P2B 107-SRB-SGE | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 107-SRB-SGH | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 107-SRB-SLE | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 107-SRB-SLH | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 107-SRB-SRE | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2B 107-SRB-SRH | 36.513 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2BE 107-SRB-CLE | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 96.5 | 90.3 | 8 000 |
| P2BE 107-SRB-CLH | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 96.5 | 90.3 | 8 000 |
| P2BE 107-SRB-CRE | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 96.5 | 90.3 | 4 000 |
| P2BE 107-SRB-CRH | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 96.5 | 90.3 | 4 000 |
| P2BE 107-SRB-SGE | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 1 700 |
| P2BE 107-SRB-SGH | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 1 700 |
| P2BE 107-SRB-SLE | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 6 000 |
| P2BE 107-SRB-SLH | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 6 000 |
| P2BE 107-SRB-SRE | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 5 100 |
| P2BE 107-SRB-SRH | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 73.8 | 81.4 | 5 100 |
| P2BE 107-TRB-STH | 36.513 | 53.975 | 47.625 | 146.05 | 187.325 | 82.5 | 104 | 3 800 |
| P2B 108-SRB-CLE | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 8 000 |
| P2B 108-SRB-CLH | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 81.4 | 8 000 |
| P2B 108-SRB-CRE | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 4 000 |
| P2B 108-SRB-CRH | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 96.5 | 90.3 | 4 000 |
| P2B 108-SRB-SGE | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 108-SRB-SGH | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 1 700 |
| P2B 108-SRB-SLE | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 108-SRB-SLH | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 6 000 |
| P2B 108-SRB-SRE | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2B 108-SRB-SRH | 38.1 | 53.975 | 47.625 | 129.381 | 174.625 | 73.8 | 81.4 | 5 100 |
| P2BE 108-SRB-CLE | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 96.5 | 90.3 | 8 000 |
| P2BE 108-SRB-CLH | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 96.5 | 90.3 | 8 000 |
| P2BE 108-SRB-CRE | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 96.5 | 90.3 | 4 000 |
| P2BE 108-SRB-CRH | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 96.5 | 90.3 | 4 000 |
| P2BE 108-SRB-SGE | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 73.8 | 81.4 | 1 700 |
| P2BE 108-SRB-SGH | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 73.8 | 81.4 | 1 700 |
| P2BE 108-SRB-SLE | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 73.8 | 81.4 | 6 000 |
| P2BE 108-SRB-SLH | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 73.8 | 81.4 | 6 000 |
| P2BE 108-SRB-SRE | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 73.8 | 81.4 | 5 100 |
| P2BE 108-SRB-SRH | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 73.8 | 81.4 | 5 100 |
| P2BE 108-TRB-STH | 38.1 | 60.325 | 53.975 | 158.75 | 200.025 | 108 | 127 | 3 200 |
| P2BE 40M-TRB-STH | 40 | 60.325 | 53.975 | 158.75 | 200.025 | 108 | 127 | 3 200 |
| SYNT 40 F | 40 | 60 | 60 | 170 | 205 | 96.5 | 90 | 3 800 |
| SYNT 40 FTF | 40 | 60 | 60 | 170 | 205 | 96.5 | 90 | 1 900 |
| SYNT 40 FTS | 40 | 60 | 60 | 170 | 205 | 96.5 | 90 | 5 900 |
| SYNT 40 L | 40 | 60 | 60 | 170 | 205 | 96.5 | 90 | 3 800 |
| SYNT 40 LTF | 40 | 60 | 60 | 170 | 205 | 96.5 | 90 | 1 900 |
| SYNT 40 LTS | 40 | 60 | 60 | 170 | 205 | 96.5 | 90 | 5 900 |
| P2BE 110-TRB-STH | 41.275 | 60.325 | 53.975 | 158.75 | 200.025 | 108 | 127 | 3 200 |
| P2B 111-SRB-CLE | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 7 500 |
| P2B 111-SRB-CLH | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 7 500 |
| P2B 111-SRB-CRE | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 3 500 |
| P2B 111-SRB-CRH | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 3 500 |
| P2B 111-SRB-SGE | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 1 600 |
| P2B 111-SRB-SGH | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 1 600 |
| P2B 111-SRB-SLE | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 5 300 |
| P2B 111-SRB-SLH | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 5 300 |
| P2B 111-SRB-SRE | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 4 500 |
| P2B 111-SRB-SRH | 42.863 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 4 500 |
| P2BE 111-SRB-CLE | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 102 | 98.3 | 7 500 |
| P2BE 111-SRB-CLH | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 102 | 98.3 | 7 500 |
| P2BE 111-SRB-CRE | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 102 | 98.3 | 3 500 |
| P2BE 111-SRB-CRH | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 102 | 98.3 | 3 500 |
| P2BE 111-SRB-SGE | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 77 | 88.1 | 1 600 |
| P2BE 111-SRB-SGH | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 77 | 88.1 | 1 600 |
| P2BE 111-SRB-SLE | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 77 | 88.1 | 5 300 |
| P2BE 111-SRB-SLH | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 77 | 88.1 | 5 300 |
| P2BE 111-SRB-SRE | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 77 | 88.1 | 4 500 |
| P2BE 111-SRB-SRH | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 77 | 88.1 | 4 500 |
| P2BE 111-TRB-STH | 42.863 | 60.325 | 53.975 | 158.75 | 200.025 | 108 | 127 | 3 200 |
| P2B 112-SRB-CLE | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 7 500 |
| P2B 112-SRB-CLH | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 7 500 |
| P2B 112-SRB-CRE | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 3 500 |
| P2B 112-SRB-CRH | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 102 | 98.3 | 3 500 |
| P2B 112-SRB-SGE | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 1 600 |
| P2B 112-SRB-SGH | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 1 600 |
| P2B 112-SRB-SLE | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 5 300 |
| P2B 112-SRB-SLH | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 5 300 |
| P2B 112-SRB-SRE | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 4 500 |
| P2B 112-SRB-SRH | 44.45 | 58.738 | 53.975 | 142.081 | 187.325 | 77 | 88.1 | 4 500 |
| P2BE 112-SRB-CLE | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 102 | 98.3 | 7 500 |
| P2BE 112-SRB-CLH | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 102 | 98.3 | 7 500 |
| P2BE 112-SRB-CRE | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 102 | 98.3 | 3 500 |
| P2BE 112-SRB-CRH | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 102 | 98.3 | 3 500 |
| P2BE 112-SRB-SGE | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 77 | 88.1 | 1 600 |
| P2BE 112-SRB-SGH | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 77 | 88.1 | 1 600 |
| P2BE 112-SRB-SLE | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 77 | 88.1 | 5 300 |
| P2BE 112-SRB-SLH | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 77 | 88.1 | 5 300 |
| P2BE 112-SRB-SRE | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 77 | 88.1 | 4 500 |
| P2BE 112-SRB-SRH | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 77 | 88.1 | 4 500 |
| P2BE 112-TRB-STH | 44.45 | 63.5 | 57.15 | 177.8 | 225.425 | 139 | 163 | 2 850 |
| P2BE 45M-TRB-STH | 45 | 63.5 | 57.15 | 177.8 | 225.425 | 139 | 163 | 2 850 |
| SYNT 45 F | 45 | 60 | 60 | 170 | 205 | 102 | 98 | 3 500 |
| SYNT 45 FTF | 45 | 60 | 60 | 170 | 205 | 102 | 98 | 1 750 |
| SYNT 45 FTS | 45 | 60 | 60 | 170 | 205 | 102 | 98 | 5 400 |
| SYNT 45 L | 45 | 60 | 60 | 170 | 205 | 102 | 98 | 3 500 |
| SYNT 45 LTF | 45 | 60 | 60 | 170 | 205 | 102 | 98 | 1 750 |
| SYNT 45 LTS | 45 | 60 | 60 | 170 | 205 | 102 | 98 | 5 400 |
| P2BE 114-TRB-STH | 47.625 | 63.5 | 57.15 | 177.8 | 225.425 | 139 | 163 | 2 850 |
| P2B 115-SRB-CLE | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 7 000 |
| P2B 115-SRB-CLH | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 7 000 |
| P2B 115-SRB-CRE | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 3 300 |
| P2B 115-SRB-CRH | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 3 300 |
| P2B 115-SRB-SGE | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 1 450 |
| P2B 115-SRB-SGH | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 1 450 |
| P2B 115-SRB-SLE | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 5 000 |
| P2B 115-SRB-SLH | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 5 000 |
| P2B 115-SRB-SRE | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 4 100 |
| P2B 115-SRB-SRH | 49.213 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 4 100 |
| P2BE 115-SRB-CLE | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 7 000 |
| P2BE 115-SRB-CLH | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 7 000 |
| P2BE 115-SRB-CRE | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 3 300 |
| P2BE 115-SRB-CRH | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 3 300 |
| P2BE 115-SRB-SGE | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 1 450 |
| P2BE 115-SRB-SGH | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 1 450 |
| P2BE 115-SRB-SLE | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 5 000 |
| P2BE 115-SRB-SLH | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 5 000 |
| P2BE 115-SRB-SRE | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 4 100 |
| P2BE 115-SRB-SRH | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 4 100 |
| P2BE 115-TRB-STH | 49.213 | 63.5 | 57.15 | 177.8 | 225.425 | 139 | 163 | 2 850 |
| P2BE 50M-TRB-STH | 50 | 63.5 | 57.15 | 177.8 | 225.425 | 139 | 163 | 2 850 |
| SYNT 50 F | 50 | 70 | 70 | 210 | 255 | 104 | 108 | 3 300 |
| SYNT 50 FTF | 50 | 70 | 70 | 210 | 255 | 104 | 108 | 1 550 |
| SYNT 50 FTS | 50 | 70 | 70 | 210 | 255 | 104 | 108 | 4 500 |
| SYNT 50 L | 50 | 70 | 70 | 210 | 255 | 104 | 108 | 3 300 |
| SYNT 50 LTF | 50 | 70 | 70 | 210 | 255 | 104 | 108 | 1 550 |
| SYNT 50 LTS | 50 | 70 | 70 | 210 | 255 | 104 | 108 | 4 500 |
| P2B 200-SRB-CLE | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 7 000 |
| P2B 200-SRB-CLH | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 7 000 |
| P2B 200-SRB-CRE | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 3 300 |
| P2B 200-SRB-CRH | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 104 | 107 | 3 300 |
| P2B 200-SRB-SGE | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 1 450 |
| P2B 200-SRB-SGH | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 1 450 |
| P2B 200-SRB-SLE | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 5 000 |
| P2B 200-SRB-SLH | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 5 000 |
| P2B 200-SRB-SRE | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 4 100 |
| P2B 200-SRB-SRH | 50.8 | 58.738 | 57.15 | 162.719 | 212.725 | 84.5 | 100 | 4 100 |
| P2BE 200-SRB-CLE | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 7 000 |
| P2BE 200-SRB-CLH | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 7 000 |
| P2BE 200-SRB-CRE | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 3 300 |
| P2BE 200-SRB-CRH | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 104 | 107 | 3 300 |
| P2BE 200-SRB-SGE | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 1 450 |
| P2BE 200-SRB-SGH | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 1 450 |
| P2BE 200-SRB-SLE | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 5 000 |
| P2BE 200-SRB-SLH | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 5 000 |
| P2BE 200-SRB-SRE | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 4 100 |
| P2BE 200-SRB-SRH | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 84.5 | 100 | 4 100 |
| P2BE 200-TRB-STH | 50.8 | 63.5 | 57.15 | 177.8 | 225.425 | 139 | 163 | 2 850 |
| P2BE 55M-TRB-STH | 55 | 66.675 | 63.5 | 196.85 | 244.475 | 151 | 186 | 2 500 |
| SYNT 55 F | 55 | 70 | 70 | 210 | 255 | 125 | 137 | 3 100 |
| SYNT 55 FTF | 55 | 70 | 70 | 210 | 255 | 125 | 137 | 1 550 |
| SYNT 55 FTS | 55 | 70 | 70 | 210 | 255 | 125 | 137 | 4 500 |
| SYNT 55 L | 55 | 70 | 70 | 210 | 255 | 125 | 137 | 3 100 |
| SYNT 55 LTF | 55 | 70 | 70 | 210 | 255 | 125 | 137 | 1 550 |
| SYNT 55 LTS | 55 | 70 | 70 | 210 | 255 | 125 | 137 | 4 500 |
| P2B 203-SRB-CLE | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 125 | 127 | 6 300 |
| P2B 203-SRB-CLH | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 125 | 127 | 6 300 |
| P2B 203-SRB-CRE | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 125 | 127 | 3 100 |
| P2B 203-SRB-CRH | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 125 | 127 | 3 100 |
| P2B 203-SRB-SGE | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 99.6 | 118 | 1 300 |
| P2B 203-SRB-SGH | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 99.6 | 118 | 1 300 |
| P2B 203-SRB-SLE | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 99.6 | 118 | 4 500 |
| P2B 203-SRB-SLH | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 99.6 | 118 | 4 500 |
| P2B 203-SRB-SRE | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 99.6 | 118 | 3 700 |
| P2B 203-SRB-SRH | 55.563 | 60.325 | 63.5 | 177.006 | 225.425 | 99.6 | 118 | 3 700 |
| P2BE 203-SRB-CLE | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 125 | 127 | 6 300 |
| P2BE 203-SRB-CLH | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 125 | 127 | 6 300 |
| P2BE 203-SRB-CRE | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 125 | 127 | 3 100 |
| P2BE 203-SRB-CRH | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 125 | 127 | 3 100 |
| P2BE 203-SRB-SGE | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 99.6 | 118 | 1 300 |
| P2BE 203-SRB-SGH | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 99.6 | 118 | 1 300 |
| P2BE 203-SRB-SLE | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 99.6 | 118 | 4 500 |
| P2BE 203-SRB-SLH | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 99.6 | 118 | 4 500 |
| P2BE 203-SRB-SRE | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 99.6 | 118 | 3 700 |
| P2BE 203-SRB-SRH | 55.563 | 66.675 | 63.5 | 198.438 | 244.475 | 99.6 | 118 | 3 700 |
| P2BE 203-TRB-STH | 55.563 | 66.675 | 63.5 | 196.85 | 244.475 | 151 | 186 | 2 500 |
| P2BE 204-TRB-STH | 57.15 | 73.025 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P4BE 204-TRB-STH | 57.15 | 88.9 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P2BE 60M-TRB-STH | 60 | 73.025 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P4BE 60M-TRB-STH | 60 | 88.9 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| SYNT 60 F | 60 | 80 | 80 | 230 | 275 | 156 | 166 | 2 900 |
| SYNT 60 FTF | 60 | 80 | 80 | 230 | 275 | 156 | 166 | 1 450 |
| SYNT 60 FTS | 60 | 80 | 80 | 230 | 275 | 156 | 166 | 4 100 |
| SYNT 60 L | 60 | 80 | 80 | 230 | 275 | 156 | 166 | 2 900 |
| SYNT 60 LTF | 60 | 80 | 80 | 230 | 275 | 156 | 166 | 1 450 |
| SYNT 60 LTS | 60 | 80 | 80 | 230 | 275 | 156 | 166 | 4 100 |
| P2B 207-SRB-CLE | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 5 000 |
| P2B 207-SRB-CLH | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 5 000 |
| P2B 207-SRB-CRE | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 2 700 |
| P2B 207-SRB-CRH | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 2 700 |
| P2B 207-SRB-SGE | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 1 100 |
| P2B 207-SRB-SGH | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 1 100 |
| P2B 207-SRB-SLE | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 800 |
| P2B 207-SRB-SLH | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 800 |
| P2B 207-SRB-SRE | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 100 |
| P2B 207-SRB-SRH | 61.913 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 100 |
| P2BE 207-SRB-CLE | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 5 000 |
| P2BE 207-SRB-CLH | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 5 000 |
| P2BE 207-SRB-CRE | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 2 700 |
| P2BE 207-SRB-CRH | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 2 700 |
| P2BE 207-SRB-SGE | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 1 100 |
| P2BE 207-SRB-SGH | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 1 100 |
| P2BE 207-SRB-SLE | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 800 |
| P2BE 207-SRB-SLH | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 800 |
| P2BE 207-SRB-SRE | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 100 |
| P2BE 207-SRB-SRH | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 100 |
| P2BE 207-TRB-STH | 61.913 | 73.025 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P4BE 207-SRB-CLE | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 5 000 |
| P4BE 207-SRB-CLH | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 5 000 |
| P4BE 207-SRB-CRE | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 2 700 |
| P4BE 207-SRB-CRH | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 2 700 |
| P4BE 207-SRB-SGE | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 1 100 |
| P4BE 207-SRB-SGH | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 1 100 |
| P4BE 207-SRB-SLE | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 800 |
| P4BE 207-SRB-SLH | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 800 |
| P4BE 207-SRB-SRE | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 100 |
| P4BE 207-SRB-SRH | 61.913 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 100 |
| P4BE 207-TRB-STH | 61.913 | 88.9 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P2B 208-SRB-CLE | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 5 000 |
| P2B 208-SRB-CLH | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 5 000 |
| P2B 208-SRB-CRE | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 2 700 |
| P2B 208-SRB-CRH | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 193 | 183 | 2 700 |
| P2B 208-SRB-SGE | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 1 100 |
| P2B 208-SRB-SGH | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 1 100 |
| P2B 208-SRB-SLE | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 800 |
| P2B 208-SRB-SLH | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 800 |
| P2B 208-SRB-SRE | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 100 |
| P2B 208-SRB-SRH | 63.5 | 68.263 | 69.85 | 184.944 | 234.95 | 148 | 183 | 3 100 |
| P2BE 208-SRB-CLE | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 5 000 |
| P2BE 208-SRB-CLH | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 5 000 |
| P2BE 208-SRB-CRE | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 2 700 |
| P2BE 208-SRB-CRH | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 193 | 183 | 2 700 |
| P2BE 208-SRB-SGE | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 1 100 |
| P2BE 208-SRB-SGH | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 1 100 |
| P2BE 208-SRB-SLE | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 800 |
| P2BE 208-SRB-SLH | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 800 |
| P2BE 208-SRB-SRE | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 100 |
| P2BE 208-SRB-SRH | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 148 | 183 | 3 100 |
| P2BE 208-TRB-STH | 63.5 | 73.025 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P4BE 208-SRB-CLE | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 5 000 |
| P4BE 208-SRB-CLH | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 5 000 |
| P4BE 208-SRB-CRE | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 2 700 |
| P4BE 208-SRB-CRH | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 193 | 183 | 2 700 |
| P4BE 208-SRB-SGE | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 1 100 |
| P4BE 208-SRB-SGH | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 1 100 |
| P4BE 208-SRB-SLE | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 800 |
| P4BE 208-SRB-SLH | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 800 |
| P4BE 208-SRB-SRE | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 100 |
| P4BE 208-SRB-SRH | 63.5 | 88.9 | 69.85 | 217.488 | 266.7 | 147 | 183 | 3 100 |
| P4BE 208-TRB-STH | 63.5 | 88.9 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P2BE 65M-TRB-STH | 65 | 73.025 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| P4BE 65M-TRB-STH | 65 | 88.9 | 69.85 | 215.9 | 266.7 | 173 | 220 | 2 250 |
| SYNT 65 F | 65 | 80 | 80 | 230 | 280 | 193 | 216 | 2 700 |
| SYNT 65 FTF | 65 | 80 | 80 | 230 | 280 | 193 | 216 | 1 350 |
| SYNT 65 FTS | 65 | 80 | 80 | 230 | 280 | 193 | 216 | 3 800 |
| SYNT 65 L | 65 | 80 | 80 | 230 | 280 | 193 | 216 | 2 700 |
| SYNT 65 LTF | 65 | 80 | 80 | 230 | 280 | 193 | 216 | 1 350 |
| SYNT 65 LTS | 65 | 80 | 80 | 230 | 280 | 193 | 216 | 3 800 |
| P2B 211-SRB-CLE | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 211-SRB-CLH | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 211-SRB-CRE | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 211-SRB-CRH | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 211-SRB-SGE | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 211-SRB-SGH | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 211-SRB-SLE | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 211-SRB-SLH | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 211-SRB-SRE | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2B 211-SRB-SRH | 68.263 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2BE 211-SRB-CLE | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 211-SRB-CLH | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 211-SRB-CRE | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 211-SRB-CRH | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 211-SRB-SGE | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 211-SRB-SGH | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 211-SRB-SLE | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 211-SRB-SLH | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 211-SRB-SRE | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 211-SRB-SRH | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 211-TRB-STH | 68.263 | 76.2 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P4BE 211-SRB-CLE | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 211-SRB-CLH | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 211-SRB-CRE | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 211-SRB-CRH | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 211-SRB-SGE | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 211-SRB-SGH | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 211-SRB-SLE | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 211-SRB-SLH | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 211-SRB-SRE | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 211-SRB-SRH | 68.263 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 211-TRB-STH | 68.263 | 101.6 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P2B 212-SRB-CLE | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 212-SRB-CLH | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 212-SRB-CRE | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 212-SRB-CRH | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 212-SRB-SGE | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 212-SRB-SGH | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 212-SRB-SLE | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 212-SRB-SLH | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 212-SRB-SRE | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2B 212-SRB-SRH | 69.85 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2BE 212-SRB-CLE | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 212-SRB-CLH | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 212-SRB-CRE | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 212-SRB-CRH | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 212-SRB-SGE | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 212-SRB-SGH | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 212-SRB-SLE | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 212-SRB-SLH | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 212-SRB-SRE | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 212-SRB-SRH | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 212-TRB-STH | 69.85 | 76.2 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P4BE 212-SRB-CLE | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 212-SRB-CLH | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 212-SRB-CRE | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 212-SRB-CRH | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 212-SRB-SGE | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 212-SRB-SGH | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 212-SRB-SLE | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 212-SRB-SLH | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 212-SRB-SRE | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 212-SRB-SRH | 69.85 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 212-TRB-STH | 69.85 | 101.6 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P2BE 70M-TRB-STH | 70 | 76.2 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P4BE 70M-TRB-STH | 70 | 101.6 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| SYNT 70 F | 70 | 90 | 95 | 260 | 315 | 208 | 228 | 2 600 |
| SYNT 70 FTF | 70 | 90 | 95 | 260 | 315 | 208 | 228 | 1 300 |
| SYNT 70 FTS | 70 | 90 | 95 | 260 | 315 | 208 | 228 | 3 600 |
| SYNT 70 L | 70 | 90 | 95 | 260 | 315 | 208 | 228 | 2 600 |
| SYNT 70 LTF | 70 | 90 | 95 | 260 | 315 | 208 | 228 | 1 300 |
| SYNT 70 LTS | 70 | 90 | 95 | 260 | 315 | 208 | 228 | 3 600 |
| P2B 215-SRB-CLE | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 215-SRB-CLH | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 215-SRB-CRE | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 215-SRB-CRH | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 215-SRB-SGE | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 215-SRB-SGH | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 215-SRB-SLE | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 215-SRB-SLH | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 215-SRB-SRE | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2B 215-SRB-SRE-Y | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2B 215-SRB-SRH | 74.613 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2BE 215-SRB-CLE | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 215-SRB-CLH | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 215-SRB-CRE | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 215-SRB-CRH | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 215-SRB-SGE | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 215-SRB-SGH | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 215-SRB-SLE | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 215-SRB-SLH | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 215-SRB-SRE | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 215-SRB-SRH | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 215-TRB-STH | 74.613 | 76.2 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P4BE 215-SRB-CLE | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 215-SRB-CLH | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 215-SRB-CRE | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 215-SRB-CRH | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 215-SRB-SGE | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 215-SRB-SGH | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 215-SRB-SLE | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 215-SRB-SLH | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 215-SRB-SRE | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 215-SRB-SRH | 74.613 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 215-TRB-STH | 74.613 | 101.6 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P2BE 75M-TRB-STH | 75 | 76.2 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P4BE 75M-TRB-STH | 75 | 101.6 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| SYNT 75 F | 75 | 90 | 95 | 260 | 320 | 212 | 240 | 2 500 |
| SYNT 75 FTF | 75 | 90 | 95 | 260 | 320 | 212 | 240 | 1 250 |
| SYNT 75 FTS | 75 | 90 | 95 | 260 | 320 | 212 | 240 | 3 300 |
| SYNT 75 L | 75 | 90 | 95 | 260 | 320 | 212 | 240 | 2 500 |
| SYNT 75 LTF | 75 | 90 | 95 | 260 | 320 | 212 | 240 | 1 250 |
| SYNT 75 LTS | 75 | 90 | 95 | 260 | 320 | 212 | 240 | 3 300 |
| P2B 300-SRB-CLE | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 300-SRB-CLH | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 4 800 |
| P2B 300-SRB-CRE | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 300-SRB-CRH | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 212 | 240 | 2 500 |
| P2B 300-SRB-SGE | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 300-SRB-SGH | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 950 |
| P2B 300-SRB-SLE | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 300-SRB-SLH | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 3 400 |
| P2B 300-SRB-SRE | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2B 300-SRB-SRH | 76.2 | 68.263 | 82.55 | 211.138 | 265.113 | 158 | 208 | 2 800 |
| P2BE 300-SRB-CLE | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 300-SRB-CLH | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 4 800 |
| P2BE 300-SRB-CRE | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 300-SRB-CRH | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 212 | 240 | 2 500 |
| P2BE 300-SRB-SGE | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 300-SRB-SGH | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 950 |
| P2BE 300-SRB-SLE | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 300-SRB-SLH | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 3 400 |
| P2BE 300-SRB-SRE | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 300-SRB-SRH | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 158 | 208 | 2 800 |
| P2BE 300-TRB-STH | 76.2 | 76.2 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P4BE 300-SRB-CLE | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 300-SRB-CLH | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 4 800 |
| P4BE 300-SRB-CRE | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 300-SRB-CRH | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 212 | 240 | 2 500 |
| P4BE 300-SRB-SGE | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 300-SRB-SGH | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 950 |
| P4BE 300-SRB-SLE | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 300-SRB-SLH | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 3 400 |
| P4BE 300-SRB-SRE | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 300-SRB-SRH | 76.2 | 101.6 | 79.375 | 244.475 | 304.8 | 158 | 208 | 2 800 |
| P4BE 300-TRB-STH | 76.2 | 101.6 | 79.375 | 241.3 | 304.8 | 170 | 236 | 1 900 |
| P2BE 80M-TRB-STH | 80 | 88.9 | 95.25 | 287.338 | 355.6 | 272 | 430 | 1 550 |
| P4BE 80M-TRB-STH | 80 | 114.3 | 95.25 | 279.4 | 342.9 | 272 | 430 | 1 550 |
| SYNT 80 F | 80 | 100 | 100 | 290 | 345 | 236 | 270 | 2 300 |
| SYNT 80 FTF | 80 | 100 | 100 | 290 | 345 | 236 | 270 | 1 150 |
| SYNT 80 FTS | 80 | 100 | 100 | 290 | 345 | 236 | 270 | 3 100 |
| SYNT 80 L | 80 | 100 | 100 | 290 | 345 | 236 | 270 | 2 300 |
| SYNT 80 LTF | 80 | 100 | 100 | 290 | 345 | 236 | 270 | 1 150 |
| SYNT 80 LTS | 80 | 100 | 100 | 290 | 345 | 236 | 270 | 3 100 |
| P2B 303-SRB-CLE | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 303-SRB-CLE-Y | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 303-SRB-CLH | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 303-SRB-CLH-Y | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 303-SRB-CRE | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 303-SRB-CRE-Y | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 303-SRB-CRH | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 303-SRB-CRH-Y | 80.963 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2BA 303-SRB-CGE | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P2BA 303-SRB-CGH | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P2BA 303-SRB-CLE | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P2BA 303-SRB-CLH | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P2BA 303-SRB-CRE | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P2BA 303-SRB-CRH | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P2BE 303-SRB-CLE | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 303-SRB-CLE-Y | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 303-SRB-CLH | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 303-SRB-CLH-Y | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 303-SRB-CRE | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 303-SRB-CRE-Y | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 303-SRB-CRH | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 303-SRB-CRH-Y | 80.963 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 303-TRB-STH | 80.963 | 88.9 | 95.25 | 287.338 | 355.6 | 272 | 430 | 1 550 |
| P4BA 303-SRB-CGE | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P4BA 303-SRB-CGH | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P4BA 303-SRB-CLE | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P4BA 303-SRB-CLH | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P4BA 303-SRB-CRE | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P4BA 303-SRB-CRH | 80.963 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P4BE 303-SRB-CLE | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 303-SRB-CLE-Y | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 303-SRB-CLH | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 303-SRB-CLH-Y | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 303-SRB-CRE | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 303-SRB-CRE-Y | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 303-SRB-CRH | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 303-SRB-CRH-Y | 80.963 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 303-TRB-STH | 80.963 | 114.3 | 95.25 | 279.4 | 342.9 | 272 | 430 | 1 550 |
| P2BE 304-TRB-STH | 82.55 | 88.9 | 95.25 | 287.338 | 355.6 | 272 | 430 | 1 550 |
| P4BE 304-TRB-STH | 82.55 | 114.3 | 95.25 | 279.4 | 342.9 | 272 | 430 | 1 550 |
| P2BE 85M-TRB-STH | 85 | 88.9 | 95.25 | 287.338 | 355.6 | 272 | 430 | 1 550 |
| P4BE 85M-TRB-STH | 85 | 114.3 | 95.25 | 279.4 | 342.9 | 272 | 430 | 1 550 |
| P2B 307-SRB-CLE | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 307-SRB-CLE-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 307-SRB-CLH | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 307-SRB-CLH-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 307-SRB-CRE | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 307-SRB-CRE-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 307-SRB-CRH | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 307-SRB-CRH-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 307-SRB-SGE | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 307-SRB-SGE-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 307-SRB-SGH | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 307-SRB-SGH-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 307-SRB-SLE | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 307-SRB-SLE-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 307-SRB-SLH | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 307-SRB-SLH-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 307-SRB-SRE | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2B 307-SRB-SRE-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2B 307-SRB-SRH | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2B 307-SRB-SRH-Y | 87.313 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2BA 307-SRB-CGE | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P2BA 307-SRB-CGH | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P2BA 307-SRB-CLE | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P2BA 307-SRB-CLH | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P2BA 307-SRB-CRE | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P2BA 307-SRB-CRH | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P2BE 307-SRB-CLE | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 307-SRB-CLE-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 307-SRB-CLH | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 307-SRB-CLH-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 307-SRB-CRE | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 307-SRB-CRE-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 307-SRB-CRH | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 307-SRB-CRH-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 307-SRB-SGE | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 307-SRB-SGE-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 307-SRB-SGH | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 307-SRB-SGH-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 307-SRB-SLE | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 307-SRB-SLE-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 307-SRB-SLH | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 307-SRB-SLH-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 307-SRB-SRE | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 307-SRB-SRE-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 307-SRB-SRH | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 307-SRB-SRH-Y | 87.313 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 307-TRB-STH | 87.313 | 88.9 | 95.25 | 287.338 | 355.6 | 255 | 430 | 1 550 |
| P4BA 307-SRB-CGE | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P4BA 307-SRB-CGH | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P4BA 307-SRB-CLE | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P4BA 307-SRB-CLH | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P4BA 307-SRB-CRE | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P4BA 307-SRB-CRH | 87.313 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P4BE 307-SRB-CLE | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 307-SRB-CLE-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 307-SRB-CLH | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 307-SRB-CLH-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 307-SRB-CRE | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 307-SRB-CRE-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 307-SRB-CRH | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 307-SRB-CRH-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 307-SRB-SGE | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 307-SRB-SGE-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 307-SRB-SGH | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 307-SRB-SGH-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 307-SRB-SLE | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 307-SRB-SLE-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 307-SRB-SLH | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 307-SRB-SLH-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 307-SRB-SRE | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 307-SRB-SRE-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 307-SRB-SRH | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 307-SRB-SRH-Y | 87.313 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 307-TRB-STH | 87.313 | 114.3 | 95.25 | 279.4 | 342.9 | 255 | 430 | 1 550 |
| P2B 308-SRB-CLE | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 308-SRB-CLE-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 308-SRB-CLH | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 308-SRB-CLH-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 3 800 |
| P2B 308-SRB-CRE | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 308-SRB-CRE-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 308-SRB-CRH | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 308-SRB-CRH-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 325 | 375 | 2 100 |
| P2B 308-SRB-SGE | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 308-SRB-SGE-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 308-SRB-SGH | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 308-SRB-SGH-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 800 |
| P2B 308-SRB-SLE | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 308-SRB-SLE-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 308-SRB-SLH | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 308-SRB-SLH-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 600 |
| P2B 308-SRB-SRE | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2B 308-SRB-SRE-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2B 308-SRB-SRH | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2B 308-SRB-SRH-Y | 88.9 | 80.963 | 95.25 | 246.063 | 330.2 | 253 | 340 | 2 300 |
| P2BA 308-SRB-CGE | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P2BA 308-SRB-CGH | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P2BA 308-SRB-CLE | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P2BA 308-SRB-CLH | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P2BA 308-SRB-CRE | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P2BA 308-SRB-CRH | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P2BE 308-SRB-CLE | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 308-SRB-CLE-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 308-SRB-CLH | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 308-SRB-CLH-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 3 800 |
| P2BE 308-SRB-CRE | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 308-SRB-CRE-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 308-SRB-CRH | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 308-SRB-CRH-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 325 | 375 | 2 100 |
| P2BE 308-SRB-SGE | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 308-SRB-SGE-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 308-SRB-SGH | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 308-SRB-SGH-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 800 |
| P2BE 308-SRB-SLE | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 308-SRB-SLE-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 308-SRB-SLH | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 308-SRB-SLH-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 600 |
| P2BE 308-SRB-SRE | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 308-SRB-SRE-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 308-SRB-SRH | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 308-SRB-SRH-Y | 88.9 | 92.075 | 95.25 | 279.4 | 355.6 | 253 | 340 | 2 300 |
| P2BE 308-TRB-STH | 88.9 | 88.9 | 95.25 | 287.338 | 355.6 | 272 | 430 | 1 550 |
| P4BA 308-SRB-CGE | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P4BA 308-SRB-CGH | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 1 000 |
| P4BA 308-SRB-CLE | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P4BA 308-SRB-CLH | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 3 800 |
| P4BA 308-SRB-CRE | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P4BA 308-SRB-CRH | 88.9 | 111.125 | 114.3 | 314.325 | 387.35 | 325 | 375 | 2 100 |
| P4BE 308-SRB-CLE | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 308-SRB-CLE-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 308-SRB-CLH | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 308-SRB-CLH-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 3 800 |
| P4BE 308-SRB-CRE | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 308-SRB-CRE-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 308-SRB-CRH | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 308-SRB-CRH-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 325 | 375 | 2 100 |
| P4BE 308-SRB-SGE | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 308-SRB-SGE-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 308-SRB-SGH | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 308-SRB-SGH-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 800 |
| P4BE 308-SRB-SLE | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 308-SRB-SLE-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 308-SRB-SLH | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 308-SRB-SLH-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 600 |
| P4BE 308-SRB-SRE | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 308-SRB-SRE-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 308-SRB-SRH | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 308-SRB-SRH-Y | 88.9 | 114.3 | 95.25 | 282.575 | 355.6 | 253 | 340 | 2 300 |
| P4BE 308-TRB-STH | 88.9 | 114.3 | 95.25 | 279.4 | 342.9 | 272 | 430 | 1 550 |
| P2BE 90M-TRB-STH | 90 | 88.9 | 95.25 | 287.338 | 355.6 | 272 | 430 | 1 550 |
| P4BE 90M-TRB-STH | 90 | 114.3 | 95.25 | 279.4 | 342.9 | 272 | 430 | 1 550 |
| SYNT 90 F | 90 | 110 | 112 | 320 | 380 | 325 | 375 | 2 100 |
| SYNT 90 FTF | 90 | 110 | 112 | 320 | 380 | 325 | 375 | 1 050 |
| SYNT 90 FTS | 90 | 110 | 112 | 320 | 380 | 325 | 375 | 2 800 |
| SYNT 90 L | 90 | 110 | 112 | 320 | 380 | 325 | 375 | 2 100 |
| SYNT 90 LTF | 90 | 110 | 112 | 320 | 380 | 325 | 375 | 1 050 |
| SYNT 90 LTS | 90 | 110 | 112 | 320 | 380 | 325 | 375 | 2 800 |
| P2B 311-SRB-CLE | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 311-SRB-CLE-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 311-SRB-CLH | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 311-SRB-CLH-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 311-SRB-CRE | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 311-SRB-CRE-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 311-SRB-CRH | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 311-SRB-CRH-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 311-SRB-SGE | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 311-SRB-SGE-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 311-SRB-SGH | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 311-SRB-SGH-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 311-SRB-SLE | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 311-SRB-SLE-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 311-SRB-SLH | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 311-SRB-SLH-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 311-SRB-SRE | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 311-SRB-SRE-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 311-SRB-SRH | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 311-SRB-SRH-Y | 93.663 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P4BA 311-SRB-CGE | 93.663 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 900 |
| P4BA 311-SRB-CGH | 93.663 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 900 |
| P4BA 311-SRB-CLE | 93.663 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 3 400 |
| P4BA 311-SRB-CLH | 93.663 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 3 400 |
| P4BA 311-SRB-CRE | 93.663 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 2 000 |
| P4BA 311-SRB-CRH | 93.663 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 2 000 |
| P4BE 311-SRB-CLE | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 311-SRB-CLE-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 311-SRB-CLH | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 311-SRB-CLH-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 311-SRB-CRE | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 311-SRB-CRE-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 311-SRB-CRH | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 311-SRB-CRH-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 311-SRB-SGE | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 311-SRB-SGE-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 311-SRB-SGH | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 311-SRB-SGH-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 311-SRB-SLE | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 311-SRB-SLE-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 311-SRB-SLH | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 311-SRB-SLH-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 311-SRB-SRE | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 311-SRB-SRE-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 311-SRB-SRH | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 311-SRB-SRH-Y | 93.663 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 100M-TRB-STH | 100 | 114.3 | 107.95 | 317.5 | 387.35 | 375 | 610 | 1 500 |
| SYNT 100 F | 100 | 120 | 125 | 350 | 410 | 425 | 490 | 2 000 |
| SYNT 100 FTF | 100 | 120 | 125 | 350 | 410 | 425 | 490 | 1 000 |
| SYNT 100 FTS | 100 | 120 | 125 | 350 | 410 | 425 | 490 | 2 500 |
| SYNT 100 L | 100 | 120 | 125 | 350 | 410 | 425 | 490 | 2 000 |
| SYNT 100 LTF | 100 | 120 | 125 | 350 | 410 | 425 | 490 | 1 000 |
| SYNT 100 LTS | 100 | 120 | 125 | 350 | 410 | 425 | 490 | 2 500 |
| P2B 315-SRB-CLE | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 315-SRB-CLE-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 315-SRB-CLH | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 315-SRB-CLH-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 315-SRB-CRE | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 315-SRB-CRE-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 315-SRB-CRH | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 315-SRB-CRH-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 315-SRB-SGE | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 315-SRB-SGE-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 315-SRB-SGH | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 315-SRB-SGH-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 315-SRB-SLE | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 315-SRB-SLE-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 315-SRB-SLH | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 315-SRB-SLH-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 315-SRB-SRE | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 315-SRB-SRE-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 315-SRB-SRH | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 315-SRB-SRH-Y | 100.013 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P4BA 315-SRB-CGE | 100.013 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 900 |
| P4BA 315-SRB-CGH | 100.013 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 900 |
| P4BA 315-SRB-CLE | 100.013 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 3 400 |
| P4BA 315-SRB-CLH | 100.013 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 3 400 |
| P4BA 315-SRB-CRE | 100.013 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 2 000 |
| P4BA 315-SRB-CRH | 100.013 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 2 000 |
| P4BE 315-SRB-CLE | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 315-SRB-CLE-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 315-SRB-CLH | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 315-SRB-CLH-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 315-SRB-CRE | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 315-SRB-CRE-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 315-SRB-CRH | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 315-SRB-CRH-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 315-SRB-SGE | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 315-SRB-SGE-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 315-SRB-SGH | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 315-SRB-SGH-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 315-SRB-SLE | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 315-SRB-SLE-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 315-SRB-SLH | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 315-SRB-SLH-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 315-SRB-SRE | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 315-SRB-SRE-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 315-SRB-SRH | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 315-SRB-SRH-Y | 100.013 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 315-TRB-STH | 100.013 | 114.3 | 107.95 | 317.5 | 387.35 | 375 | 610 | 1 500 |
| P2B 400-SRB-CLE | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 400-SRB-CLE-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 400-SRB-CLH | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 400-SRB-CLH-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 3 400 |
| P2B 400-SRB-CRE | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 400-SRB-CRE-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 400-SRB-CRH | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 400-SRB-CRH-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 426 | 489 | 2 000 |
| P2B 400-SRB-SGE | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 400-SRB-SGE-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 400-SRB-SGH | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 400-SRB-SGH-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 700 |
| P2B 400-SRB-SLE | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 400-SRB-SLE-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 400-SRB-SLH | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 400-SRB-SLH-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 200 |
| P2B 400-SRB-SRE | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 400-SRB-SRE-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 400-SRB-SRH | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P2B 400-SRB-SRH-Y | 101.6 | 89.694 | 104.775 | 282.575 | 361.95 | 311 | 415 | 2 100 |
| P4BA 400-SRB-CGE | 101.6 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 900 |
| P4BA 400-SRB-CGH | 101.6 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 900 |
| P4BA 400-SRB-CLE | 101.6 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 3 400 |
| P4BA 400-SRB-CLH | 101.6 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 3 400 |
| P4BA 400-SRB-CRE | 101.6 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 2 000 |
| P4BA 400-SRB-CRH | 101.6 | 120.65 | 125.425 | 346.075 | 419.1 | 426 | 489 | 2 000 |
| P4BE 400-SRB-CLE | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 400-SRB-CLE-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 400-SRB-CLH | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 400-SRB-CLH-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 3 400 |
| P4BE 400-SRB-CRE | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 400-SRB-CRE-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 400-SRB-CRH | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 400-SRB-CRH-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 426 | 489 | 2 000 |
| P4BE 400-SRB-SGE | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 400-SRB-SGE-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 400-SRB-SGH | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 400-SRB-SGH-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 700 |
| P4BE 400-SRB-SLE | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 000 |
| P4BE 400-SRB-SLE-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 000 |
| P4BE 400-SRB-SLH | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 400-SRB-SLH-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 200 |
| P4BE 400-SRB-SRE | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 400-SRB-SRE-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 400-SRB-SRH | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 400-SRB-SRH-Y | 101.6 | 114.3 | 107.95 | 320.675 | 387.35 | 311 | 415 | 2 100 |
| P4BE 400-TRB-STH | 101.6 | 114.3 | 107.95 | 317.5 | 387.35 | 375 | 610 | 1 500 |
| P4BE 110M-TRB-STH | 110 | 117.475 | 120.65 | 342.9 | 422.275 | 454 | 735 | 1 300 |
| P4BE 407-SRB-SRH | 112.7 | 117.475 | 120.65 | 350.838 | 422.275 | 408 | 560 | 1 900 |
| P4BA 407-SRB-CGE | 112.713 | 133.35 | 152.4 | 388.938 | 466.725 | 572 | 640 | 800 |
| P4BA 407-SRB-CGH | 112.713 | 133.35 | 152.4 | 388.938 | 466.725 | 572 | 640 | 800 |
| P4BA 407-SRB-CLE | 112.713 | 133.35 | 152.4 | 388.938 | 466.725 | 572 | 640 | 3 000 |
| P4BA 407-SRB-CLH | 112.713 | 133.35 | 152.4 | 388.938 | 466.725 | 572 | 640 | 3 000 |
| P4BA 407-SRB-CRE | 112.713 | 133.35 | 152.4 | 388.938 | 466.725 | 572 | 640 | 1 700 |
| P4BA 407-SRB-CRH | 112.713 | 133.35 | 152.4 | 388.938 | 466.725 | 572 | 640 | 1 700 |
| P4BE 407-SRB-CGE | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 572 | 640 | 850 |
| P4BE 407-SRB-CGH | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 572 | 640 | 850 |
| P4BE 407-SRB-CLE | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 572 | 640 | 3 000 |
| P4BE 407-SRB-CLH | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 572 | 640 | 3 000 |
| P4BE 407-SRB-CRE | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 572 | 640 | 1 700 |
| P4BE 407-SRB-CRH | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 572 | 640 | 1 700 |
| P4BE 407-SRB-SRE | 112.713 | 117.475 | 120.65 | 350.838 | 422.275 | 408 | 560 | 1 900 |
| P4BE 407-TRB-STH | 112.713 | 117.475 | 120.65 | 342.9 | 422.275 | 454 | 735 | 1 300 |
| P4BE 408-SRB-SRE | 114.3 | 117.475 | 120.65 | 350.838 | 422.275 | 408 | 560 | 1 900 |
| P4BE 408-SRB-SRH | 114.3 | 117.475 | 120.65 | 350.838 | 422.275 | 408 | 560 | 1 900 |
| P4BE 408-TRB-STH | 114.3 | 117.475 | 120.65 | 342.9 | 422.275 | 454 | 735 | 1 300 |
| P4BE 115M-TRB-STH | 115 | 117.475 | 120.65 | 342.9 | 422.275 | 454 | 735 | 1 300 |
| P4BE 125M-TRB-STH | 125 | 130.175 | 139.7 | 393.7 | 469.9 | 618 | 1 040 | 1 150 |
| P4BE 415-SRB-SRH | 125.4 | 130.175 | 139.7 | 398.463 | 469.9 | 547 | 801 | 1 650 |
| P4BA 415-SRB-CGE | 125.413 | 149.225 | 152.4 | 419.1 | 511.175 | 758 | 930 | 700 |
| P4BA 415-SRB-CGH | 125.413 | 149.225 | 152.4 | 419.1 | 511.175 | 758 | 930 | 700 |
| P4BA 415-SRB-CLE | 125.413 | 149.225 | 152.4 | 419.1 | 511.175 | 758 | 930 | 2 600 |
| P4BA 415-SRB-CLH | 125.413 | 149.225 | 152.4 | 419.1 | 511.175 | 758 | 930 | 2 600 |
| P4BA 415-SRB-CRE | 125.413 | 149.225 | 152.4 | 419.1 | 511.175 | 758 | 930 | 1 550 |
| P4BA 415-SRB-CRH | 125.413 | 149.225 | 152.4 | 419.1 | 511.175 | 758 | 930 | 1 550 |
| P4BE 415-SRB-CGE | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 758 | 930 | 750 |
| P4BE 415-SRB-CGH | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 758 | 930 | 750 |
| P4BE 415-SRB-CLE | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 758 | 930 | 2 600 |
| P4BE 415-SRB-CLH | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 758 | 930 | 2 600 |
| P4BE 415-SRB-CRE | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 758 | 930 | 1 550 |
| P4BE 415-SRB-CRH | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 758 | 930 | 1 550 |
| P4BE 415-SRB-SRE | 125.413 | 130.175 | 139.7 | 398.463 | 469.9 | 547 | 801 | 1 650 |
| P4BE 415-TRB-STH | 125.413 | 130.175 | 139.7 | 393.7 | 469.9 | 618 | 1 040 | 1 150 |
| P4BE 500-TRB-STH | 127 | 130.175 | 139.7 | 393.7 | 469.9 | 618 | 1 040 | 1 150 |
