Фланцевый роликоподшипниковый узел

Элемент фланцевого роликоподшипника состоит из сферических или конических роликоподшипников, установленных в чугунном корпусе, который может быть прикреплен болтом к стенке машины. Эти устройства запечатаны и смазаны и могут использоваться в любое время. Такие устройства охватывают широкий круг требований. Ни метрические, ни британские серии не стандартизированы, но наши роликовые подшипники могут быть взаимозаменяемы по размеру с наиболее распространенными конструкциями на рынке.

Свяжитесь с нами

Описание продукции

Designation	Shaft diameter	Unit dimensions			Basic load ratings		Limiting speed
		Bolt distance	Lengtht	Total width	dynamic	static
	d_a [mm]↑↓	J [mm]	L [mm]	T [mm]	C [kN]	C₀[kN]	[r/min]
F4BE 103-SRB-SGE	30.163	88.9	117.475	72.231	73.8	81.4	1 700
F4BE 103-SRB-SGH	30.163	88.9	117.475	72.231	73.8	81.4	1 700
F4BE 103-SRB-SLE	30.163	88.9	117.475	72.231	73.8	81.4	6 000
F4BE 103-SRB-SLH	30.163	88.9	117.475	72.231	73.8	81.4	6 000
F4BE 103-SRB-SRE	30.163	88.9	117.475	72.231	73.8	81.4	5 100
F4BE 103-SRB-SRH	30.163	88.9	117.475	72.231	73.8	81.4	5 100
F4BE 103-TRB-STH	30.163	73.025	95.25	71.438	54.3	64	4 300
F4BE 104-SRB-SGE	31.75	88.9	117.475	72.231	73.8	81.4	1 700
F4BE 104-SRB-SGH	31.75	88.9	117.475	72.231	73.8	81.4	1 700
F4BE 104-SRB-SLE	31.75	88.9	117.475	72.231	73.8	81.4	6 000
F4BE 104-SRB-SLH	31.75	88.9	117.475	72.231	73.8	81.4	6 000
F4BE 104-SRB-SRE	31.75	88.9	117.475	72.231	73.8	81.4	5 100
F4BE 104-SRB-SRH	31.75	88.9	117.475	72.231	73.8	81.4	5 100
F4BE 104-TRB-STH	31.75	73.025	95.25	71.438	54.3	64	4 300
F4BE 106-TRB-STH	34.925	88.9	117.475	77.788	88.2	104	3 800
F4BE 35M-TRB-STH	35	88.9	117.475	77.788	82.5	104	3 800
FYNT 35 F	35	140	159	72.5	86.5	85	4 100
FYNT 35 L	35	140	159	72.5	86.5	85	4 100
F4B 107-SRB-CRE	36.513	89.713	117.475	64.294	96.5	90.3	8 000
F4B 107-SRB-CRH	36.513	89.713	117.475	66.675	96.5	90.3	8 000
F4B 107-SRB-SRE	36.513	89.713	117.475	76.994	73.8	81.4	5 100
F4B 107-SRB-SRH	36.513	89.713	117.475	78.581	73.8	81.4	5 100
F4BE 107-SRB-CLE	36.513	88.9	117.475	59.134	96.5	90.3	8 000
F4BE 107-SRB-CLH	36.513	88.9	117.475	59.134	96.5	90.3	8 000
F4BE 107-SRB-CRE	36.513	88.9	117.475	59.134	96.5	90.3	3 800
F4BE 107-SRB-CRH	36.513	88.9	117.475	59.134	96.5	90.3	3 800
F4BE 107-SRB-SGE	36.513	88.9	117.475	72.231	73.8	81.4	1 700
F4BE 107-SRB-SGH	36.513	88.9	117.475	72.231	73.8	81.4	1 700
F4BE 107-SRB-SLE	36.513	88.9	117.475	72.231	73.8	81.4	6 000
F4BE 107-SRB-SLH	36.513	88.9	117.475	72.231	73.8	81.4	6 000
F4BE 107-SRB-SRE	36.513	88.9	117.475	72.231	73.8	81.4	5 100
F4BE 107-SRB-SRH	36.513	88.9	117.475	72.231	73.8	81.4	5 100
F4BE 107-TRB-STH	36.513	88.9	117.475	77.788	82.5	104	3 800
F4B 108-SRB-CRE	38.1	89.713	117.475	64.294	96.5	90.3	8 000
F4B 108-SRB-CRH	38.1	89.713	117.475	66.675	96.5	90.3	8 000
F4B 108-SRB-SRE	38.1	89.713	117.475	76.994	73.8	81.4	5 100
F4B 108-SRB-SRH	38.1	89.713	117.475	78.581	73.8	81.4	5 100
F4BE 108-SRB-CLE	38.1	104.775	136.525	59.134	96.5	90.3	8 000
F4BE 108-SRB-CLH	38.1	104.775	136.525	59.134	96.5	90.3	8 000
F4BE 108-SRB-CRE	38.1	104.775	136.525	59.134	96.5	90.3	3 800
F4BE 108-SRB-CRH	38.1	104.775	136.525	59.134	96.5	90.3	3 800
F4BE 108-SRB-SGE	38.1	104.775	136.525	73.819	73.8	81.4	1 600
F4BE 108-SRB-SGH	38.1	104.775	136.525	73.819	73.8	81.4	1 600
F4BE 108-SRB-SLE	38.1	104.775	136.525	73.819	73.8	81.4	5 100
F4BE 108-SRB-SLH	38.1	104.775	136.525	73.819	73.8	81.4	6 000
F4BE 108-SRB-SRE	38.1	104.775	136.525	73.819	73.8	81.4	5 100
F4BE 108-SRB-SRH	38.1	104.775	136.525	73.819	73.8	81.4	5 100
F4BE 108-TRB-STH	38.1	104.775	136.525	88.9	108	127	3 200
F4BE 40M-TRB-STH	40	104.775	136.525	88.9	108	127	3 200
FYNT 40 F	40	160	179	72.5	96.5	90	3 800
FYNT 40 L	40	160	179	72.5	96.5	90	3 800
F4BE 110-TRB-STH	41.275	104.775	136.525	88.9	108	127	3 200
F4B 111-SRB-CRE	42.863	98.831	130.175	65.088	102	98.3	3 500
F4B 111-SRB-CRH	42.863	98.831	130.175	66.675	102	98.3	3 500
F4B 111-SRB-SRE	42.863	98.831	130.175	80.169	77	88.1	4 500
F4B 111-SRB-SRH	42.863	98.831	130.175	81.756	77	88.1	4 500
F4BE 111-SRB-CLE	42.863	104.775	136.525	59.928	102	98.3	7 500
F4BE 111-SRB-CLH	42.863	104.775	136.525	59.928	102	98.3	7 500
F4BE 111-SRB-CRE	42.863	104.775	136.525	59.928	102	98.3	3 500
F4BE 111-SRB-CRH	42.863	104.775	136.525	59.928	102	98.3	3 500
F4BE 111-SRB-SGE	42.863	104.775	136.525	76.994	77	88.1	1 600
F4BE 111-SRB-SGH	42.863	104.775	136.525	76.994	77	88.1	1 600
F4BE 111-SRB-SLE	42.863	104.775	136.525	76.994	77	88.1	5 300
F4BE 111-SRB-SLH	42.863	104.775	136.525	76.994	77	88.1	5 300
F4BE 111-SRB-SRE	42.863	104.775	136.525	76.994	77	88.1	4 500
F4BE 111-SRB-SRH	42.863	104.775	136.525	76.994	77	88.1	4 500
F4BE 111-TRB-STH	42.863	104.775	136.525	88.9	108	127	3 200
F4B 112-SRB-CRE	44.45	98.831	130.175	65.088	102	98.3	3 500
F4B 112-SRB-CRH	44.45	98.831	130.175	66.675	102	98.3	3 500
F4B 112-SRB-SRE	44.45	98.831	130.175	80.169	77	88.1	4 500
F4B 112-SRB-SRH	44.45	98.831	130.175	81.756	77	88.1	4 500
F4BE 112-SRB-CLE	44.45	111.125	139.7	59.928	102	98.3	7 500
F4BE 112-SRB-CLH	44.45	111.125	139.7	59.928	102	98.3	7 500
F4BE 112-SRB-CRE	44.45	111.125	139.7	59.928	102	98.3	3 500
F4BE 112-SRB-CRH	44.45	111.125	139.7	59.928	102	98.3	3 500
F4BE 112-SRB-SGE	44.45	111.125	139.7	75.406	77	88.1	1 600
F4BE 112-SRB-SGH	44.45	111.125	139.7	75.406	77	88.1	1 600
F4BE 112-SRB-SLE	44.45	111.125	139.7	75.406	77	88.1	5 300
F4BE 112-SRB-SLH	44.45	111.125	139.7	75.406	77	88.1	5 300
F4BE 112-SRB-SRE	44.45	111.125	139.7	75.406	77	88.1	4 500
F4BE 112-SRB-SRH	44.45	111.125	139.7	75.406	77	88.1	4 500
F4BE 112-TRB-STH	44.45	111.125	142.875	89.694	139	163	2 850
F4BE 45M-TRB-STH	45	111.125	142.875	89.694	139	163	2 850
FYNT 45 F	45	160	179	72.5	102	98	3 500
FYNT 45 L	45	160	179	72.5	102	98	3 500
F4BE 114-TRB-STH	47.625	111.125	142.875	89.694	139	163	2 850
F4B 115-SRB-CRE	49.213	103.175	134.938	65.088	104	107	3 300
F4B 115-SRB-CRH	49.213	103.175	134.938	65.881	104	107	3 300
F4B 115-SRB-SRE	49.213	103.175	134.938	80.169	84.5	100	4 100
F4B 115-SRB-SRH	49.213	103.175	134.938	80.963	84.5	100	4 100
F4BE 115-SRB-CLE	49.213	111.125	139.7	59.928	104	107	7 000
F4BE 115-SRB-CLH	49.213	111.125	139.7	59.928	104	107	7 000
F4BE 115-SRB-CRE	49.213	111.125	139.7	59.928	104	107	3 300
F4BE 115-SRB-CRH	49.213	111.125	139.7	59.928	104	107	3 300
F4BE 115-SRB-SGE	49.213	111.125	139.7	75.406	84.5	100	1 450
F4BE 115-SRB-SGH	49.213	111.125	139.7	75.406	84.5	100	1 450
F4BE 115-SRB-SLE	49.213	111.125	139.7	75.406	84.5	100	5 000
F4BE 115-SRB-SLH	49.213	111.125	139.7	75.406	84.5	100	5 000
F4BE 115-SRB-SRE	49.213	111.125	139.7	75.406	84.5	100	4 100
F4BE 115-SRB-SRH	49.213	111.125	139.7	75.406	84.5	100	4 100
F4BE 115-TRB-STH	49.213	111.125	142.875	89.694	139	163	2 850
F4B 50M-SRB-CRE	50	103.175	134.938	65.088	104	107	3 300
F4B 50M-SRB-CRH	50	103.175	134.938	65.881	104	107	3 300
F4BE 50M-SRB-CLE	50	111.125	139.7	59.134	104	107	7 000
F4BE 50M-SRB-CLH	50	111.125	139.7	59.134	104	107	7 000
F4BE 50M-SRB-CRE	50	111.125	139.7	59.134	104	107	3 300
F4BE 50M-SRB-CRH	50	111.125	139.7	59.134	104	107	3 300
F4BE 50M-TRB-STH	50	111.125	142.875	89.694	139	163	2 850
FYNT 50 F	50	170	192	72.7	104	108	3 300
FYNT 50 L	50	170	192	72.7	104	108	3 300
F4B 200-SRB-CRE	50.8	103.175	134.938	65.088	104	107	3 300
F4B 200-SRB-CRH	50.8	103.175	134.938	65.881	104	107	3 300
F4B 200-SRB-SRE	50.8	103.175	134.938	80.169	84.5	100	4 100
F4B 200-SRB-SRH	50.8	103.175	134.938	80.963	84.5	100	4 100
F4BE 200-SRB-CLE	50.8	111.125	139.7	59.928	104	107	7 000
F4BE 200-SRB-CLH	50.8	111.125	139.7	59.928	104	107	7 000
F4BE 200-SRB-CRE	50.8	111.125	139.7	59.928	104	107	3 300
F4BE 200-SRB-CRH	50.8	111.125	139.7	59.928	104	107	3 300
F4BE 200-SRB-SGE	50.8	111.125	139.7	75.406	84.5	100	1 450
F4BE 200-SRB-SGH	50.8	111.125	139.7	75.406	84.5	100	1 450
F4BE 200-SRB-SLE	50.8	111.125	139.7	75.406	84.5	100	5 000
F4BE 200-SRB-SLH	50.8	111.125	139.7	75.406	84.5	100	5 000
F4BE 200-SRB-SRE	50.8	111.125	139.7	75.406	84.5	100	4 100
F4BE 200-SRB-SRH	50.8	111.125	139.7	75.406	84.5	100	4 100
F4BE 200-TRB-STH	50.8	111.125	142.875	89.694	139	163	2 850
F4BE 55M-TRB-STH	55	123.825	158.75	98.425	151	186	2 500
FYNT 55 F	55	180	210	73.6	125	137	3 100
FYNT 55 L	55	180	210	73.6	125	137	3 100
F4B 203-SRB-CRE	55.563	114.3	149.225	67.469	125	127	3 100
F4B 203-SRB-CRH	55.563	114.3	149.225	68.263	125	127	3 100
F4B 203-SRB-SRE	55.563	114.3	149.225	85.725	99.6	118	3 700
F4B 203-SRB-SRH	55.563	114.3	149.225	86.519	99.6	118	3 700
F4BE 203-SRB-CLE	55.563	123.825	158.75	63.897	125	127	6 300
F4BE 203-SRB-CLH	55.563	123.825	158.75	63.897	125	127	6 300
F4BE 203-SRB-CRE	55.563	123.825	158.75	63.897	125	127	3 100
F4BE 203-SRB-CRH	55.563	123.825	158.75	63.897	125	127	3 100
F4BE 203-SRB-SGE	55.563	120.65	158.75	81.756	99.6	118	1 300
F4BE 203-SRB-SGH	55.563	120.65	158.75	81.756	99.6	118	1 300
F4BE 203-SRB-SLE	55.563	120.65	158.75	81.756	99.6	118	4 500
F4BE 203-SRB-SLH	55.563	120.65	158.75	81.756	99.6	118	4 500
F4BE 203-SRB-SRE	55.563	120.65	158.75	81.756	99.6	118	3 700
F4BE 203-SRB-SRH	55.563	120.65	158.75	81.756	99.6	118	3 700
F4BE 203-TRB-STH	55.563	123.825	158.75	98.425	151	186	2 500
F4BE 204-TRB-STH	57.15	136.525	174.625	107.95	173	220	2 250
F4BE 60M-TRB-STH	60	136.525	174.625	107.95	173	220	2 250
FYNT 60 F	60	190	225	78.7	156	166	2 900
FYNT 60 L	60	190	225	78.7	156	166	2 900
F4B 207-SRB-CRE	61.913	121.437	155.575	67.469	193	183	2 700
F4B 207-SRB-CRH	61.913	121.437	155.575	68.263	193	183	2 700
F4B 207-SRB-SRE	61.913	121.437	155.575	89.694	148	183	3 100
F4B 207-SRB-SRH	61.913	121.437	155.575	90.488	148	183	3 100
F4BE 207-SRB-CLE	61.913	136.525	174.625	69.85	193	183	5 000
F4BE 207-SRB-CLH	61.913	136.525	174.625	69.85	193	183	5 000
F4BE 207-SRB-CRE	61.913	136.525	174.625	69.85	193	183	2 700
F4BE 207-SRB-CRH	61.913	136.525	174.625	69.85	193	183	2 700
F4BE 207-SRB-SGE	61.913	136.525	174.625	88.106	148	183	1 100
F4BE 207-SRB-SGH	61.913	136.525	174.625	88.106	148	183	1 100
F4BE 207-SRB-SLE	61.913	136.525	174.625	88.106	148	183	3 800
F4BE 207-SRB-SLH	61.913	136.525	174.625	88.106	148	183	3 800
F4BE 207-SRB-SRE	61.913	136.525	174.625	88.106	148	183	3 100
F4BE 207-SRB-SRH	61.913	136.525	174.625	88.106	148	183	3 100
F4BE 207-TRB-STH	61.913	136.525	174.625	107.95	173	220	2 250
F4BED 207-SRB-CRE	61.913	136.525	174.625	69.85	193	183	2 700
F4BED 207-SRB-CRH	61.913	136.525	174.625	69.85	193	183	2 700
F4B 208-SRB-CRE	63.5	121.437	155.575	67.469	193	183	2 700
F4B 208-SRB-CRH	63.5	121.437	155.575	68.263	193	183	2 700
F4B 208-SRB-SRE	63.5	121.437	155.575	89.694	148	183	3 100
F4B 208-SRB-SRH	63.5	121.437	155.575	90.488	148	183	3 100
F4BE 208-SRB-CLE	63.5	136.525	174.625	69.85	193	183	5 000
F4BE 208-SRB-CLH	63.5	136.525	174.625	69.85	193	183	5 000
F4BE 208-SRB-CRE	63.5	136.525	174.625	69.85	193	183	2 700
F4BE 208-SRB-CRH	63.5	136.525	174.625	69.85	193	183	2 700
F4BE 208-SRB-SGE	63.5	136.525	174.625	88.106	148	183	1 100
F4BE 208-SRB-SGH	63.5	136.525	174.625	88.106	148	183	1 100
F4BE 208-SRB-SLE	63.5	136.525	174.625	88.106	148	183	3 800
F4BE 208-SRB-SLH	63.5	136.525	174.625	88.106	148	183	3 800
F4BE 208-SRB-SRE	63.5	136.525	174.625	88.106	148	183	3 100
F4BE 208-SRB-SRH	63.5	136.525	174.625	88.106	148	183	3 100
F4BE 208-TRB-STH	63.5	136.525	174.625	107.95	173	220	2 250
F4BE 65M-TRB-STH	65	136.525	174.625	107.95	173	220	2 250
FYNT 65 F	65	152	190	80.3	193	216	2 700
FYNT 65 L	65	152	190	80.3	193	216	2 700
F4B 211-SRB-CRE	68.263	141.288	182.563	71.438	212	240	2 500
F4B 211-SRB-CRH	68.263	141.288	182.563	73.025	212	240	2 500
F4B 211-SRB-SRE	68.263	141.288	182.563	96.044	158	208	2 800
F4B 211-SRB-SRH	68.263	141.288	182.563	97.631	158	208	2 800
F4BE 211-SRB-CLE	68.263	152.4	193.675	73.422	212	240	4 800
F4BE 211-SRB-CLH	68.263	152.4	193.675	73.422	212	240	4 800
F4BE 211-SRB-CRE	68.263	152.4	193.675	73.422	212	240	2 500
F4BE 211-SRB-CRH	68.263	152.4	193.675	73.422	212	240	2 500
F4BE 211-SRB-SGE	68.263	152.4	193.675	98.425	158	208	950
F4BE 211-SRB-SGH	68.263	152.4	193.675	98.425	158	208	950
F4BE 211-SRB-SLE	68.263	152.4	193.675	98.425	158	208	3 400
F4BE 211-SRB-SLH	68.263	152.4	193.675	98.425	158	208	3 400
F4BE 211-SRB-SRE	68.263	152.4	193.675	98.425	158	208	2 800
F4BE 211-SRB-SRH	68.263	152.4	193.675	98.425	158	208	2 800
F4BE 211-TRB-STH	68.263	152.4	196.85	119.063	170	236	1 900
F4B 212-SRB-CRE	69.85	141.288	182.563	71.438	212	240	2 500
F4B 212-SRB-CRH	69.85	141.288	182.563	73.025	212	240	2 500
F4B 212-SRB-SRE	69.85	141.288	182.563	96.044	158	208	2 800
F4B 212-SRB-SRH	69.85	141.288	182.563	97.631	158	208	2 800
F4BE 212-SRB-CLE	69.85	152.4	193.675	73.422	212	240	4 800
F4BE 212-SRB-CLH	69.85	152.4	193.675	73.422	212	240	4 800
F4BE 212-SRB-CRE	69.85	152.4	193.675	73.422	212	240	2 500
F4BE 212-SRB-CRH	69.85	152.4	193.675	73.422	212	240	2 500
F4BE 212-SRB-SGE	69.85	152.4	193.675	98.425	158	208	950
F4BE 212-SRB-SGH	69.85	152.4	193.675	98.425	158	208	950
F4BE 212-SRB-SLE	69.85	152.4	193.675	98.425	158	208	3 400
F4BE 212-SRB-SLH	69.85	152.4	193.675	98.425	158	208	3 400
F4BE 212-SRB-SRE	69.85	152.4	193.675	98.425	158	208	2 800
F4BE 212-SRB-SRH	69.85	152.4	193.675	98.425	158	208	2 800
F4BE 212-TRB-STH	69.85	152.4	196.85	119.063	170	236	1 900
F4BE 70M-TRB-STH	70	152.4	196.85	119.063	170	236	1 900
FYNT 70 F	70	152	196	81.3	208	228	2 600
FYNT 70 L	70	152	196	81.3	208	228	2 600
F4B 215-SRB-CRE	74.613	141.288	182.563	71.438	212	240	2 500
F4B 215-SRB-CRH	74.613	141.288	182.563	73.025	212	240	2 500
F4B 215-SRB-SRE	74.613	141.288	182.563	96.044	158	208	2 800
F4B 215-SRB-SRH	74.613	141.288	182.563	97.631	158	208	2 800
F4BE 215-SRB-CLE	74.613	152.4	193.675	73.422	212	240	4 800
F4BE 215-SRB-CLH	74.613	152.4	193.675	73.422	212	240	4 800
F4BE 215-SRB-CRE	74.613	152.4	193.675	73.422	212	240	2 500
F4BE 215-SRB-CRH	74.613	152.4	193.675	73.422	212	240	2 500
F4BE 215-SRB-SGE	74.613	152.4	193.675	98.425	158	208	950
F4BE 215-SRB-SGH	74.613	152.4	193.675	98.425	158	208	950
F4BE 215-SRB-SLE	74.613	152.4	193.675	98.425	158	208	3 400
F4BE 215-SRB-SLH	74.613	152.4	193.675	98.425	158	208	3 400
F4BE 215-SRB-SRE	74.613	152.4	193.675	98.425	158	208	2 800
F4BE 215-SRB-SRH	74.613	152.4	193.675	98.425	158	208	2 800
F4BE 215-TRB-STH	74.613	152.4	196.85	119.063	170	236	1 900
F4BED 215-SRB-CRE	74.613	152.4	193.675	73.422	212	240	2 500
F4BED 215-SRB-CRH	74.613	152.4	193.675	73.422	212	240	2 500
F4BE 75M-TRB-STH	75	152.4	196.85	119.063	170	236	1 900
FYNT 75 F	75	170	210	81.3	212	240	2 500
FYNT 75 L	75	170	210	81.3	212	240	2 500
F4BE 300-SRB-CLE	76.2	152.4	193.675	73.422	212	240	4 800
F4BE 300-SRB-CLH	76.2	152.4	193.675	73.422	212	240	4 800
F4BE 300-SRB-CRE	76.2	152.4	193.675	73.422	212	240	2 500
F4BE 300-SRB-CRH	76.2	152.4	193.675	73.422	212	240	2 500
F4BE 300-SRB-SGE	76.2	152.4	193.675	98.425	158	208	950
F4BE 300-SRB-SGH	76.2	152.4	193.675	98.425	158	208	950
F4BE 300-SRB-SLE	76.2	152.4	193.675	98.425	158	208	3 400
F4BE 300-SRB-SLH	76.2	152.4	193.675	98.425	158	208	3 400
F4BE 300-SRB-SRE	76.2	152.4	193.675	98.425	158	208	2 800
F4BE 300-SRB-SRH	76.2	152.4	193.675	98.425	158	208	2 800
F4BE 300-TRB-STH	76.2	152.4	196.85	119.063	170	236	1 900
F4BE 80M-TRB-STH	80	177.8	234.95	133.35	272	430	1 550
FYNT 80 F	80	170	210	83	236	270	2 300
FYNT 80 L	80	170	210	83	236	270	2 300
F4B 303-SRB-CRE	80.963	170.663	209.55	86.519	325	375	2 100
F4B 303-SRB-CRH	80.963	170.663	209.55	87.313	325	375	2 100
F4BE 303-TRB-STH	80.963	177.8	234.95	133.35	272	430	1 550
F4BE 304-TRB-STH	82.55	177.8	234.95	133.35	272	430	1 550
F4BE 85M-TRB-STH	85	177.8	234.95	133.35	272	430	1 550
F4B 307-SRB-CRE	87.313	170.663	209.55	86.519	325	375	2 100
F4B 307-SRB-CRH	87.313	170.663	209.55	87.313	325	375	2 100
F4B 307-SRB-SRE	87.313	170.663	209.55	111.125	253	340	2 300
F4B 307-SRB-SRH	87.313	170.663	209.55	112.713	253	340	2 300
F4BE 307-SRB-CLE	87.313	177.8	222.25	83.344	325	375	3 800
F4BE 307-SRB-CLE-Y	87.313	177.8	222.25	83.344	325	375	3 800
F4BE 307-SRB-CLH	87.313	177.8	222.25	83.344	325	375	3 800
F4BE 307-SRB-CLH-Y	87.313	177.8	222.25	83.344	325	375	3 800
F4BE 307-SRB-CRE	87.313	177.8	222.25	83.344	325	375	2 100
F4BE 307-SRB-CRE-Y	87.313	177.8	222.25	83.344	325	375	2 100
F4BE 307-SRB-CRH	87.313	177.8	222.25	83.344	325	375	2 100
F4BE 307-SRB-CRH-Y	87.313	177.8	222.25	83.344	325	375	2 100
F4BE 307-SRB-SGE	87.313	177.8	222.25	107.95	253	340	800
F4BE 307-SRB-SGE-Y	87.313	177.8	222.25	107.95	253	340	800
F4BE 307-SRB-SGH	87.313	177.8	222.25	107.95	253	340	800
F4BE 307-SRB-SGH-Y	87.313	177.8	222.25	107.95	253	340	800
F4BE 307-SRB-SLE	87.313	177.8	222.25	107.95	253	340	2 600
F4BE 307-SRB-SLE-Y	87.313	177.8	222.25	107.95	253	340	2 600
F4BE 307-SRB-SLH	87.313	177.8	222.25	107.95	253	340	2 600
F4BE 307-SRB-SLH-Y	87.313	177.8	222.25	107.95	253	340	2 600
F4BE 307-SRB-SRE	87.313	177.8	222.25	107.95	253	340	2 300
F4BE 307-SRB-SRE-Y	87.313	177.8	222.25	107.95	253	340	2 300
F4BE 307-SRB-SRH	87.313	177.8	222.25	107.95	253	340	2 300
F4BE 307-SRB-SRH-Y	87.313	177.8	222.25	107.95	253	340	2 300
F4BE 307-TRB-STH	87.313	177.8	234.95	133.35	255	430	1 550
F4B 308-SRB-CRE	88.9	170.663	209.55	86.519	325	375	2 100
F4B 308-SRB-CRH	88.9	170.663	209.55	87.313	325	375	2 100
F4B 308-SRB-SRE	88.9	170.663	209.55	111.125	253	340	2 300
F4B 308-SRB-SRH	88.9	170.663	209.55	112.713	253	340	2 300
F4BE 308-SRB-CLE	88.9	177.8	222.25	83.344	325	375	3 800
F4BE 308-SRB-CLE-Y	88.9	177.8	222.25	83.344	325	375	3 800
F4BE 308-SRB-CLH	88.9	177.8	222.25	83.344	325	375	3 800
F4BE 308-SRB-CLH-Y	88.9	177.8	222.25	83.344	325	375	3 800
F4BE 308-SRB-CRE	88.9	177.8	222.25	83.344	325	375	2 100
F4BE 308-SRB-CRE-Y	88.9	177.8	222.25	83.344	325	375	2 100
F4BE 308-SRB-CRH	88.9	177.8	222.25	83.344	325	375	2 100
F4BE 308-SRB-CRH-Y	88.9	177.8	222.25	83.344	325	375	2 100
F4BE 308-SRB-SGE	88.9	177.8	222.25	107.95	253	340	800
F4BE 308-SRB-SGE-Y	88.9	177.8	222.25	107.95	253	340	800
F4BE 308-SRB-SGH	88.9	177.8	222.25	107.95	253	340	800
F4BE 308-SRB-SGH-Y	88.9	177.8	222.25	107.95	253	340	800
F4BE 308-SRB-SLE	88.9	177.8	222.25	107.95	253	340	2 600
F4BE 308-SRB-SLE-Y	88.9	177.8	222.25	107.95	253	340	2 600
F4BE 308-SRB-SLH	88.9	177.8	222.25	107.95	253	340	2 600
F4BE 308-SRB-SLH-Y	88.9	177.8	222.25	107.95	253	340	2 600
F4BE 308-SRB-SRE	88.9	177.8	222.25	107.95	253	340	2 300
F4BE 308-SRB-SRE-Y	88.9	177.8	222.25	107.95	253	340	2 300
F4BE 308-SRB-SRH	88.9	177.8	222.25	107.95	253	340	2 300
F4BE 308-SRB-SRH-Y	88.9	177.8	222.25	107.95	253	340	2 300
F4BE 308-TRB-STH	88.9	177.8	234.95	133.35	272	430	1 550
F4BE 90M-TRB-STH	90	177.8	234.95	133.35	272	430	1 550
FYNT 90 F	90	198	250	93.5	325	375	2 100
FYNT 90 L	90	198	250	93.5	325	375	2 100
F4B 311-SRB-CRE	93.663	193.294	234.95	92.869	426	489	2 000
F4B 311-SRB-CRH	93.663	193.294	234.95	93.663	426	489	2 000
F4B 311-SRB-SRE	93.663	193.294	234.95	123.825	311	415	2 100
F4B 311-SRB-SRH	93.663	193.294	234.95	125.413	311	415	2 100
F4BE 311-SRB-CLE	93.663	196.85	247.65	91.281	426	489	3 400
F4BE 311-SRB-CLE-Y	93.663	196.85	247.65	91.281	426	489	3 400
F4BE 311-SRB-CLH	93.663	196.85	247.65	91.281	426	489	3 400
F4BE 311-SRB-CLH-Y	93.663	196.85	247.65	91.281	426	489	3 400
F4BE 311-SRB-CRE	93.663	196.85	247.65	91.281	426	489	2 000
F4BE 311-SRB-CRE-Y	93.663	196.85	247.65	91.281	426	489	2 000
F4BE 311-SRB-CRH	93.663	196.85	247.65	91.281	426	489	2 000
F4BE 311-SRB-CRH-Y	93.663	196.85	247.65	91.281	426	489	2 000
F4BE 311-SRB-SGE	93.663	196.85	247.65	122.238	311	415	700
F4BE 311-SRB-SGE-Y	93.663	196.85	247.65	122.238	311	415	700
F4BE 311-SRB-SGH	93.663	196.85	247.65	122.238	311	415	700
F4BE 311-SRB-SGH-Y	93.663	196.85	247.65	122.238	311	415	700
F4BE 311-SRB-SLE	93.663	196.85	247.65	122.238	311	415	2 200
F4BE 311-SRB-SLE-Y	93.663	196.85	247.65	122.238	311	415	2 200
F4BE 311-SRB-SLH	93.663	196.85	247.65	122.238	311	415	2 200
F4BE 311-SRB-SLH-Y	93.663	196.85	247.65	122.238	311	415	2 200
F4BE 311-SRB-SRE	93.663	196.85	247.65	122.238	311	415	2 100
F4BE 311-SRB-SRE-Y	93.663	196.85	247.65	122.238	311	415	2 100
F4BE 311-SRB-SRH	93.663	196.85	247.65	122.238	311	415	2 100
F4BE 311-SRB-SRH-Y	93.663	196.85	247.65	122.238	311	415	2 100
F4B 100M-SRB-CRE	100	193.294	234.95	92.869	426	489	2 000
F4B 100M-SRB-CRH	100	193.294	234.95	93.663	426	489	2 000
F4B 100M-SRB-SRE	100	193.294	234.95	123.825	311	415	2 100
F4B 100M-SRB-SRH	100	193.294	234.95	125.413	311	415	2 100
F4B 315-SRB-CRE	100	193.294	234.95	92.869	426	489	2 000
F4B 315-SRB-CRH	100	193.294	234.95	93.663	426	489	2 000
F4B 315-SRB-SRE	100	193.294	234.95	123.825	311	415	2 100
F4B 315-SRB-SRH	100	193.294	234.95	125.413	311	415	2 100
F4BE 100M-TRB-STH	100	196.85	260.35	165.1	375	610	1 500
FYNT 100 F	100	219	270	98.9	425	490	2 000
FYNT 100 L	100	219	270	98.9	425	490	2 000
F4BE 315-SRB-CLE	100.013	196.85	247.65	91.281	426	489	3 400
F4BE 315-SRB-CLE-Y	100.013	196.85	247.65	91.281	426	489	3 400
F4BE 315-SRB-CLH	100.013	196.85	247.65	91.281	426	489	3 400
F4BE 315-SRB-CLH-Y	100.013	196.85	247.65	91.281	426	489	3 400
F4BE 315-SRB-CRE	100.013	196.85	247.65	91.281	426	489	2 000
F4BE 315-SRB-CRE-Y	100.013	196.85	247.65	91.281	426	489	2 000
F4BE 315-SRB-CRH	100.013	196.85	247.65	91.281	426	489	2 000
F4BE 315-SRB-CRH-Y	100.013	196.85	247.65	91.281	426	489	2 000
F4BE 315-SRB-SGE	100.013	196.85	247.65	122.238	311	415	700
F4BE 315-SRB-SGE-Y	100.013	196.85	247.65	122.238	311	415	700
F4BE 315-SRB-SGH	100.013	196.85	247.65	122.238	311	415	700
F4BE 315-SRB-SGH-Y	100.013	196.85	247.65	122.238	311	415	700
F4BE 315-SRB-SLE	100.013	196.85	247.65	122.238	311	415	2 200
F4BE 315-SRB-SLE-Y	100.013	196.85	247.65	122.238	311	415	2 200
F4BE 315-SRB-SLH	100.013	196.85	247.65	122.238	311	415	2 200
F4BE 315-SRB-SLH-Y	100.013	196.85	247.65	122.238	311	415	2 200
F4BE 315-SRB-SRE	100.013	196.85	247.65	122.238	311	415	2 000
F4BE 315-SRB-SRE-Y	100.013	196.85	247.65	122.238	311	415	2 000
F4BE 315-SRB-SRH	100.013	196.85	247.65	122.238	311	415	2 000
F4BE 315-SRB-SRH-Y	100.013	196.85	247.65	122.238	311	415	2 000
F4BE 315-TRB-STH	100.013	196.85	260.35	165.1	375	610	1 500
F4B 400-SRB-CRE	101.6	193.294	234.95	92.869	426	489	2 000
F4B 400-SRB-CRH	101.6	193.294	234.95	93.663	426	489	2 000
F4B 400-SRB-SRE	101.6	193.294	234.95	123.825	311	415	2 100
F4B 400-SRB-SRH	101.6	193.294	234.95	125.413	311	415	2 100
F4BE 400-SRB-CLE	101.6	196.85	247.65	91.281	426	489	3 400
F4BE 400-SRB-CLE-Y	101.6	196.85	247.65	91.281	426	489	3 400
F4BE 400-SRB-CLH	101.6	196.85	247.65	91.281	426	489	3 400
F4BE 400-SRB-CLH-Y	101.6	196.85	247.65	91.281	426	489	3 400
F4BE 400-SRB-CRE	101.6	196.85	247.65	91.281	426	489	2 000
F4BE 400-SRB-CRE-Y	101.6	196.85	247.65	91.281	426	489	2 000
F4BE 400-SRB-CRH	101.6	196.85	247.65	91.281	426	489	2 000
F4BE 400-SRB-CRH-Y	101.6	196.85	247.65	91.281	426	489	2 000
F4BE 400-SRB-SGE	101.6	196.85	247.65	122.238	311	415	700
F4BE 400-SRB-SGE-Y	101.6	196.85	247.65	122.238	311	415	700
F4BE 400-SRB-SGH	101.6	196.85	247.65	122.238	311	415	700
F4BE 400-SRB-SGH-Y	101.6	196.85	247.65	122.238	311	415	700
F4BE 400-SRB-SLE	101.6	196.85	247.65	122.238	311	415	2 200
F4BE 400-SRB-SLE-Y	101.6	196.85	247.65	122.238	311	415	2 200
F4BE 400-SRB-SLH	101.6	196.85	247.65	122.238	311	415	2 200
F4BE 400-SRB-SLH-Y	101.6	196.85	247.65	122.238	311	415	2 200
F4BE 400-SRB-SRE	101.6	196.85	247.65	122.238	311	415	2 100
F4BE 400-SRB-SRE-Y	101.6	196.85	247.65	122.238	311	415	2 100
F4BE 400-SRB-SRH	101.6	196.85	247.65	122.238	311	415	2 100
F4BE 400-SRB-SRH-Y	101.6	196.85	247.65	122.238	311	415	2 100
F4BE 400-TRB-STH	101.6	196.85	260.35	165.1	375	610	1 500
F4BE 110M-TRB-STH	110	222.25	276.225	180.975	454	735	1 300
F4BE 407-SRB-CLE	112.713	222.25	276.225	131.763	560	640	3 000
F4BE 407-SRB-CLH	112.713	222.25	276.225	131.763	560	640	3 000
F4BE 407-SRB-CRE	112.713	222.25	276.225	131.763	560	640	1 700
F4BE 407-SRB-CRH	112.713	222.25	276.225	131.763	560	640	1 700
F4BE 407-SRB-SRE	112.713	222.25	276.225	162.719	408	560	1 900
F4BE 407-SRB-SRH	112.713	222.25	276.225	162.719	408	560	1 900
F4BE 407-TRB-STH	112.713	222.25	276.225	180.975	454	735	1 300
F4BE 408-SRB-SRE	114.3	222.25	276.225	162.719	408	560	1 900
F4BE 408-SRB-SRH	114.3	222.25	276.225	162.719	408	560	1 900
F4BE 408-TRB-STH	114.3	222.25	276.225	180.975	454	735	1 300
F4BE 115M-TRB-STH	115	222.25	276.225	180.975	454	735	1 300

Пожалуйста, оставьте нам сообщение

Продукция

Продукция

Фланцевый роликоподшипниковый узел

Описание продукции

Свяжитесь с нами

Продукция

Навигация
